Triple Offset
PRODUCT SPECIFICATIONS
TORQUE RANGE
- 80 to 800 Nm (direct)
- Up to 1,000,000 Nm on request
COMPLIANCE WITH INTERNATIONAL EXPLOSION-PROOF STANDARDS: ATEX, INMETRO, IEC-EX, EAC-EX, NEMA 7 & 9...
TYPE OF CONTROLS:
- Electromechanical SWITCH
- Hardwired
- Smart INTELLI+® (v2)
- SIL2
BC DUTY & MODULATING CLASSIFICATION:
- On-Off: Class A+
- Inching / Positioning: Class B+
- Modulating: Class III
ENVIRONMENT: IP 68 / C3 UP TO C5-M / T: -20°C ...+70°C (OPTION LOW T: -60°C)
SPECIAL CONFIGURATIONS: CORROSION PROTECTION, FIRE PROOFING, EXTREME TEMPERATURES
PRODUCTS BENEFITS
- Asynchronous motor with high starting torque & S4 Service duty
- Gears are self-locking
- Non-rotative declutch-free handwheel with electric motor priority
- INTELLI+® integrated control available: advanced control solution for your critical applications
- Double sealing
- Partial stroke test (PST) included
- Programmable timer
- Separated control box & LCS available
- Wide range of fieldbus available
- SIL certification as an option
