Manufacturing range: DN50 - DN1600 (larger diameters available on request)
Distance between flanges: API 609 - ISO 5752 - BS 5155
Installation between flanges: PN10/16/25 - ANSI150 Lbs./300 Lbs./600 Lbs.
Flanged: ISO 7005-1/2 - DIN 2501 PN10/16/25/40 - ASME B16.5 (150-300Lbs) - ASME B16.47 Series A/B (150-300Lbs) - ASME B16.1 Class 125/250 Lbs - AWWA C20
Upper flange connection: ISO 5211
Tests: ISO 5208, API598, EN 12266, ANSI/ASME B16.34, BS 1560, EN 593
Coating: Rilsan® / Inox
Work Pressure: up to 100 bar
Properties
- Triple axis offset.
- Longer useful life, minimal friction between the disc and the seat.
- Complete tightness. Class VI - ISO 5208 (Rate A)
- Self-sealing mechanism that guarantees a tight seal and low torque.
- Offset axle allows for easy seat replacement.
- The disc seat can be easily replaced without the need for special tools.
- Quick on-site maintenance.
- High performance.
- Locking device on the lower shaft on request.
- Design suitable for high pressures.
- Possibility of operation with different controls (lever control, reducer,
- pneumatic, electric, hydraulic actuator...)
- Bidirectional design on request.
- PED 2014/68.
- ATEX 2014/34/EU - ATEX II 2GDc.
- SIL IFC 61508.
- TA-LUFT VD 2440 ISO 15848 design.
General applications
- Sweet water
- Seawater
- Hot water
- Air
- Compressed air
- Feeding
- Vegetable fats and minerals
- Oils
- Refrigeration
- Ozone
- Nitrogen derivatives
- weak acids
- Concentrated and hot acids
- Chemicals
- Solvents
- Hydrocarbons
- Gases
- High temperature gases
