Fire Protection Butterfly valve - Grooved ends | TTV Valves

Fire Protection Butterfly valve - Grooved ends | TTV Valves: Reliable Fire Safety, Made Simple

The Fire Protection Butterfly valve - Grooved ends | TTV Valves is designed to deliver peace of mind and top-level safety for any fire protection system. Built for modern requirements, this valve ensures smooth, reliable operation during critical moments. Whether you are protecting commercial spaces, warehouses, or industrial sites, it stands out as a key component in your fire defense strategy.

Key Features & Benefits of Fire Protection Butterfly valve - Grooved ends | TTV Valves

  • Easy Installation: Thanks to its grooved ends, connecting this valve to your existing pipework is fast and straightforward. No need for complicated tools or installation methods.
  • Durable Construction: Crafted from high-quality materials, this valve resists corrosion and wear, even in demanding environments. It’s built to last and perform when you need it most.
  • Precise Control: The butterfly design allows for quick opening and closing, giving you total control over water flow in emergency situations. Fast response can make all the difference in fire protection.
  • Low Maintenance: The simple, robust design minimizes the risk of breakdowns and keeps maintenance costs low. You spend less time worrying about your equipment and more time focused on safety.
  • Reliable Sealing: Engineered for secure shut-off, the valve seals tightly to prevent leaks. This means you can trust it to hold back water until you need it most.
  • Universal Compatibility: Suits a wide range of systems and is compatible with standard grooved piping, making it a practical choice for both new builds and upgrades.

With the Fire Protection Butterfly valve - Grooved ends | TTV Valves, you are choosing safety, dependability, and quality. It’s an excellent solution for anyone looking to safeguard their property with a valve that combines smart design and solid engineering. Easy to use and maintain, it offers essential protection when every second counts. Choose this trusted valve for a reliable shield against fire emergencies.

Datasheet and documents

Description

Manufacturing range: DN50 - DN300

Distance between flanges: MSS SP 67

Installation between flanges: ANSI/AWWA C606-97 - ANSI 3616, ISO 4200

Flanged: ANSI B3610, DIN 2448, BS 1387, BS 3600

Upper flange connection: ISO 5211

Tests: ISO 5208, zero leakage API 598

Coating: Rilsan® / Epoxy

Work Pressure: 16 bar

Properties

  • Grooved coupling provides secure, simple and quick connection.
  • No welding or coupling flanges required.
  • The vulcanized butterfly provides a perfect seal.
  • Low maneuvering torque.
  • It is the lightest valve on the market.
  • Easy and quick assembly and disassembly.
  • Adapts to all types of pipes.
  • Aerodynamic disc design that minimizes pressure loss.
  • It does not require perfect alignment between the valve and the pipe, it allows some flexibility.
  • Valve indicated for water pipes, especially for fire protection.
  • TA-LUFT VD 2440 design.

General applications

  • Irrigation
  • Drinking water
  • Seawater
  • Water supply
  • industrial water
  • Residual water
  • Fire protection systems
  • cooling towers
  • pumping stations
  • Food industry
  • Paper industry
  • Chemical and petrochemical industry
  • Naval sector and marine environment
  • Iron and steel industry
  • Energy generation
  • oil industry
  • Sugar industry
  • cement industry
  • Mining
  • Construction
