Triple Offset
PRODUCT SPECIFICATIONS
TORQUE RANGE:
- 40 Nm and 70 Nm
COMPLIANCE WITH INTERNATIONAL EXPLOSION-PROOF STANDARDS: ATEX, IEC-EX, NEMA 7...
TYPE OF CONTROLS:
> Electromechanical SWITCH
BC DUTY & MODULATING CLASSIFICATION:
- On-Off: Class A
- Inching / Positioning : Class B
ENVIRONMENT: IP 68 / C4 ( C5 ON REQUEST) / T: -20°C ...+60°C
LINEAR APPLICATIONS
PRODUCT BENEFITS
COMPACT & OPTIMIZED DESIGN
- Super compact design
- Product architecture adapted to customers’ requirements (70 Nm)
- Multi-voltage (AC/DC) & multifrequency products : suitable whatever your location on the globe
- 24VDC, 2 wires or 12VDC 2 or 3 wires available as an option
- Short delivery time, even for voluminous projects, thanks to large production capacity.
- Nameplate with ATEX, IECEx and CSA as standards to simplify delivery
EASY TO USE
- Easy commissioning for quick installation on site: pre-wired version available (1-phase only),
- User-friendly set up of travel limitation system with a standard screwdriver. Cameblock directly accessible at the front.
- Positioner option (4-20mA)
- Manual operation via manual hexagonal output: essential for emergency intervention
- BC APP: Bernard Controls new mobile application to get access to full documentation and Assitance.
RELIABLE DESIGN
- BERNARD CONTROLS design methodology built-up on the nuclear market highly demanding requirements
- 80+ years of continuous experience and BC inventor of the compact quarter-turn electric actuator
- Extended lifetime: more than 100000 cycles attained during endurance tests in laboratory.
- Heavy duty design: full aluminum enclosure protected by durable powder coating, C4, IP68, large temperature scale.
- Compliance with international explosionproof standards : ATEX, IEC Ex...
- Self-locking at all speeds without any additional component
- S4 Motor Service Duty. Up to 120 starts per hour at peak of operation.
- Electronic torque limiter for reinforced valve security
