PRODUCT SPECIFICATIONS
TORQUE RANGE:
- 60 to 2,200 Nm (direct)
- up to 20,000 Nm on request
10 TO 120 RPM (DIRECT) & HIGH SPEED: UP TO 190 RPM (DIRECT & <300NM)
TYPE OF CONTROLS:
- Smart INTELLI+®(v2) With Fieldbus Redundant ...
- SIL2
BC DUTY & MODULATING CLASSIFICATION:
- On-Off: Class A+
- Inching/ Positioning: Class B+
- Modulating: Class III
CONNECTOR: DOUBLE-SEALING WITH INTELLI+®
ENVIRONMENT: IP 68 / C3 UP TO C5-M / T: -20°C ...+70°C
(option low T° -40°C on all models and option high T° +90°C for SWITCH versions only)
PRODUCT BENEFITS
- Wide range of speeds / up to 190 rpm according to the model
- Wide range of number of turns: from a few to 1000 or more
- Gears are self-locking at all speed
- Precise torque measurement and limitation
> Easy setting with a simple screwdriver
> Between 40 and 100% of maximum torque value
> Frictionless system for high precision and repeatability
- Innovative emergency handwheel system:
> Non-rotative handwheel with electric motor priority
> Exclusive handwheel differential system without declutch lever
- INTELLI+® integrated control available: advanced control solution for your critical applications
