ADLER FT4 3-Way Ball Valve, Wafer Full Bore

The ADLER FT4 is a three-way, wafer-type, full bore ball valve designed for installation between flanges. Construction is 3-way wafer full bore 90°, available with T-bore or L-bore ball configurations to suit specific flow plans. Size range covers DN15–DN150, pressure classes PN10–PN40, and ANSI 150–300 versions.

Construction and Materials

  • Body/inserts: ASTM A105, ASTM A479 304/304L, or 316/316L
  • Ball: ASTM A479 304/304L, ASTM A351 CF8, ASTM A479 316/316L, or ASTM A351 CF8M
  • Stem: ASTM A479 304/304L or 316/316L, anti-blowout design
  • Seats: PTFE, optional RPTFE
  • Stem sealing: PTFE/graphite chevron rings, optional FKM O-ring

Standards and Documentation

Design in accordance with EN 12516-2, ASME B16.34, ISO 14313. Flange dimensions per EN 1092-1 or ASME B16.5. Options for PED 2014/68/EU, ATEX 2014/34/EU, fire-safe ISO 10497 / API 607, ISO 15848 Class A, antistatic design, and SIL 3 capable certification for actuated valves.

T-bore vs L-bore Selection

L-bore is used for diverting a common line to one of two branches. T-bore allows more flow combinations; flow path and position feedback must be confirmed for automation to ensure correct indication and limit switch alignment.

Automation

Top flange ISO 5211 enables mounting of pneumatic or electric actuators. Torque selection should consider valve size, differential pressure, seat material, and operating frequency.

Applications

Suitable for skids, manifolds, utility networks, process water, neutral liquids, and feed/return selection lines. For oxygen, degreasing per ISO 23208 is available. For flammable or volatile media, request appropriate ATEX/fire-safe/ISO 15848 documentation.

Standard (Options)
  • DIN
  • ANSI
Connection (Options)
  • Flanged (Wafer)
Material (Options)
  • ASTM A105N
  • ASTM A479 Type 304
  • ASTM A479 Type 316
Pressure Rating (Options)
  • PN 10
  • PN 16
  • PN 25
  • PN 40
Seat (Options)
  • PTFE
  • RPTFE

Datasheet and documents

Description

Three way 90° ball valve “wafer type”, full bore, manufactured from round bar, according to EN 12516.2; ASME B16.34; ISO 14313.

Available size from DN 15 to DN 150 in carbon steel, stainless steel adn special steel.

Rating PN 10 ÷ 40 / ANSI 150 .

With  “T” bore or “L” bore type ball

Chevron ring on stem.

On request:

– with o’ring on stem (patent n°00219688).

– fire-safe execution according to ISO 10497 API 607

– fire-safe execution according to BS6755 API 607/6FA (patent n° 00219617).

– according to  PED 14/68/UE directive

– according to TPED 2010/35/UE directive

– according to ATEX 14/34/UE directive

– degreased according to ISO 23208 for oxigen serivce

– certified in safety  system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848.

Standard productions

anti blow out proof stem

construction and marking BS 5351

carbon steel valves painted with first coat of epoxy-polyammidic RAL 5012 35 microns

antistatic device

top flange ISO 5211

all valves 100% air tested under water at 100 psi

On demand accessories

PTFE seats filled glass – carbon – S.S. – bronze, metal core

cryogenic valves

stem extention

oval handle

pneumatic actuator double/single acting

electric motor

manual gear box

electric-pneumatic limit switches/solenoid valves

Certificates

– certified in safety  system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848

– ISO 9001 by L.R.

– PED DIR. 2014/68/UE by L.R.

– ATEX DIR. 2014/34/UE by B.V.

– FIRE SAFE EXECUTION BS6755/API 607 by L.R.

– FIRE SAFE TESTED ISO 10497 by L.R.

– ISO 15848 by TÜV

– ANTISTATIC DEVICE by L.R.

– EAC CERTIFICATION by B.V.
