Ball Valve - Type 37000 | Ibor Valves

Ball Valve - Type 37000 | Ibor Valves: Reliable Industrial Performance Made Simple

Experience seamless control and dependable shutoff with the Ball Valve - Type 37000 | Ibor Valves. Designed for industrial professionals seeking a trustworthy solution, this expertly engineered valve combines advanced features with everyday reliability. Enjoy peace of mind knowing your operations run smoothly and efficiently.

Features & Benefits of Ball Valve - Type 37000 | Ibor Valves

  • Easy Operation: With its simple quarter-turn mechanism, opening and closing the flow is quick and effortless—even under high-pressure conditions.
  • Durable Construction: Crafted from robust industrial materials, this valve stands up to tough environments, always delivering consistent performance.
  • Leak-Proof Solution: Precision engineering ensures tight shutoff, eliminating drips and leaks and keeping your workplace safe and clean.
  • Corrosion Resistance: Special coatings and quality materials resist rust and corrosion, even after years of demanding use.
  • Low Maintenance: The self-cleaning design reduces the need for frequent servicing, so you save time and resources in the long run.
  • Versatile Applications: Suitable for a wide range of industrial fluids, from water and oil to chemicals, making it a smart choice for various operations.
  • Reliable Seal: The floating ball design creates a reliable seal each time, preventing unwanted flow or contamination.
  • Universal Compatibility: Standard connections allow for easy installation in both new and existing pipelines, ensuring hassle-free upgrades or replacements.

Upgrade your industrial system with the Ball Valve - Type 37000 | Ibor Valves and experience the difference that true quality makes. Designed with user convenience in mind, this valve offers straightforward function and long-lasting value, so you can focus on getting the job done without interruption. Choose a solution trusted by professionals worldwide—choose reliability, safety, and efficiency.

Description

Seat design

  • Double piston effect downstream & upstream-DIB I
  • Double piston effect downstream & single piston effect upstream-DIB II
  • Seat sealing injector

Stem

  • Stem sealing injector
  • Stem or bonnet extension
  • Design according to fugitive emissions
  • Locking device

Others

  • Overlay on seat area or on all wetted parts
  • Heating or cooling jacket

Connections

Flanged End: ASME B16.5 / GOST 12815-80 / EN 1092.1

Socket Weld End: ASME B16.11

**integral nipples and available

Butt Weld End: ASME B16.25

**integral nipples and available

Threaded NPT End: ASME B1.20.1

Threaded BSPP OR BSPT: BS21

Others

Design & Certification

Normative: ANSI / DIN

Design: API 6D / ISO 14313

Face to Face: ASME B16.10 / EN 558.1 Serie 27

Top Flange: ISO 5211

Press-Temp Ratings & Thickness: ASME B16.34

Test: API 6D / API 598 / EN 12266-1

Pressure Equipment Directive: PED 2014/68/EU Mod. H1

Equipment Directive: ATEX 94/9/EC

Fire Safe: API 6FA / API 607 / ISO 10497-2

Fugitive Emissions: Class”A” acc.to ISO 15484-2

Safety integrity level: Sil 2 acc.to IEC 61508

Material: NACE MR0175 Lastest Edition

Certification:EN 10204 type 3.1, (3.2 upon request)
