Adler FB8 Spherical Tank Bottom Valve

The Adler FB8 is a wafer-type, full bore ball valve designed for direct installation at tank bottoms. The valve features a tank-side flange one DN size larger than the nominal bore, enabling compact installation and direct flanged connection to the vessel. It is typically used at discharge points where minimal installation length and robust sealing are required.

Technical Specifications

  • Type: Wafer, full bore, end-tank mounting
  • Sizes: DN40 to DN200
  • Pressure: PN10–PN16; ANSI 150 on request
  • Construction: Bar stock or cast body
  • Materials: ASTM A479 316/316L or ASTM A351 CF8M, per configuration
  • Seats: PTFE, RPTFE optional
  • Stem sealing: Chevron rings PTFE/graphite
  • Top flange: ISO 5211
  • Antistatic device: BS 5146
  • Stem: Anti blow-out design

FB8 vs FA8 Variant

The FA8 covers DN50 to DN100 with a 15° inclined stem. The FB8 range extends from DN40 to DN200, suitable for applications requiring larger nominal diameters or alternative tank flange geometries. Selection depends on vessel design and process requirements.

Standards and Available Versions

Manufactured to BS EN 12516-2, ANSI B16.34, and ISO 14313. On request: PED 2014/68/EU, ATEX 2014/34/EU, fire-safe ISO 10497 / API 607, cryogenic ISO 28921, ISO 15848 class A for fugitive emissions, and SIL 3 capable for automated valves.

Applications

Used in storage tanks, reactors, mixing vessels, and chemical or industrial liquid discharge lines compatible with 316/316L stainless steel and PTFE seat materials. For media with solids, high viscosity, or crystallization risk, cavity cleaning provisions should be considered.

Automation

ISO 5211 flange allows mounting of pneumatic (single/double acting), electric actuators, manual gearboxes, and positioners. Actuator selection is based on required torque, pressure, cycle frequency, and fail-safe position (fail-open/fail-close).

Standard (Options)
  • DIN
  • ANSI
Connection (Options)
  • Flanged (Wafer)
Material (Options)
  • ASTM A479 Type 316
  • ASTM A479 Type 316L
Pressure Rating (Options)
  • PN 10
  • PN 16

Datasheet and documents

Description

Ball valve “WAFER TYPE” end tank execution, full bore, oversize flange for connections tank, manufactured from round bar or casted, according to EN 12516.2; ASME B16.34; ISO 14313.

Available size from DN 40 to DN 200 in stainless steel and special steel

Rating PN 10 ÷ 16 – ANSI 150 on request.

Chevron ring on stem.

On request:

– with o’ring on stem (patent n°00219688).

– fire-safe execution according to ISO 10497 API 607

– fire safe execution BS6755 API 607/6FA (patent n° 00219617)

– cryogenic execution ISO 28921

– according to PED 14/68/UE directive

– according to ATEX14/34/UE directive

– degrease according to ISO 23208 oxigen service

– certified in safety system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848.

Standard productions

anti blow out proof stem

construction and marking BS 5351

carbon steel valves painted with first coat of epoxy-polyammidic RAL 5012 35 microns

antistatic device BS5146/74

top flange ISO 5211

all valves 100% air tested under water at 100 psi

On demand accessories

PTFE / glass renforced PTFE half shell

PTFE seats filled glass – carbon – S.S. – bronze, metal core

stem extensions

pneumatic actuator double/single acting

electric actuator

manual gear box

pneumatic/electro-pneumatic positioner

Certifications

– certified in safety system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848.

– ISO 9001 by L.R.

– PED DIR. 2014/68/UE by L.R.

– ATEX DIR. 2014/34/UE by B.V.

– FIRE SAFE EXECUTION BS6755/API 607 by L.R.

– FIRE SAFE TESTED ISO 10497 by L.R.

– ISO 15848 by TÜV

– ANTISTATIC DEVICE by L.R.

– EAC CERTIFICATION by B.V.
