Wafer Ball Valves - Wafer PN16 - Series 72 | Valpres: The Reliable Choice for Industrial Flow Control

Upgrade your industrial systems with the Wafer Ball Valves - Wafer PN16 - Series 72 | Valpres, a robust solution engineered for reliability and precision. Designed for businesses that value efficiency, these wafer ball valves make your operations smoother and more cost-effective.

Features and Benefits of the Wafer Ball Valves - Wafer PN16 - Series 72 | Valpres

  • Compact Design: The slim wafer-style body fits effortlessly between flanges, saving space and simplifying installation—even in tight spots.
  • Durable Construction: Crafted from high-quality materials, these valves resist corrosion and wear, ensuring a long service life even under tough industrial conditions.
  • Reliable PN16 Pressure Rating: Rated for up to 16 bar pressure, providing dependable shut-off and flow control in demanding environments.
  • Fast and Easy Operation: Simple quarter-turn handle operation makes it easy to open or close the valve quickly without needing special tools or training.
  • Leak-Free Performance: Advanced sealing systems prevent leaks, protecting your equipment and minimizing maintenance needs.
  • Versatile Application: Suitable for a wide range of fluids and gases, making it ideal for factories, plants, and industrial facilities of all types.
  • Low Maintenance: The design minimizes moving parts and components, so regular maintenance is simple and downtime is reduced.

Every Wafer Ball Valves - Wafer PN16 - Series 72 | Valpres unit is thoroughly tested to meet strict quality standards. Its compact, efficient design means it fits into your pipelines without taking up unnecessary space, all while delivering high performance. The user-friendly handle gives you full control over your processes, and the tough build means you won’t have to worry about frequent replacements.

For anyone looking to boost productivity and safety, these wafer ball valves offer a smart investment. Designed for industrial use, they help keep your operations running smoothly, whether you’re managing liquids, steam, or gases. Choose the Wafer Ball Valves - Wafer PN16 - Series 72 | Valpres for peace of mind and reliable performance every day.


Type : 723000-723004 C1-C2-C3-
Standard (Options)
  • DIN
Connection (Options)
  • Flanged (Wafer)
Material (Options)
  • ASTM A351 CF8M
  • ASTM A352 LCB
Pressure Rating (Options)
  • PN 16

Description

Valpres - Wafer Ball Valves - Wafer PN16 - 723000

Temperature range: -20°C +160°C.

Vacuum: 10-3 torr.

PositionPart nameMaterialN.° pieces
1BODYA351-CF8M1
2END CONNECTIONA479-TP316/A182-F3161
3BALLA351-CF8M/A479-TP3161
4BALL SEATTFM-MPTFE2
5BODY SEATPTFE1
6THRUST WASHERTFM-MPTFE1
7O-RINGFKM2
8STEMA479-TP316/17-4-PH1
9STEM SEATPTFE1
10O-RINGFKM1
SIZEDNCODEDYZLACEØNBØN1B1KvPNKg
1"2572300006110854xM124870119365,550764,5162,40
1"1/432723000071301004xM165482109365,5507103,8163,50
1"1/240723000081401104xM1663,5931311506,5--174164,50
2"50723000101551254xM1682101,513,511506,5709301,3166,70
2"1/265723000121801454xM16103128,515,514709--545,71610,90
3"80723000141901608xM161221381514709--872,51614,00
4"100723000182201808xM1615215318,517709--1363,31620,90

Available versions: ANSI150M: 723100; ANSI150U: 723101.

Valpres - Wafer Ball Valves - Wafer PN16 V-Ball - 723004 C1-C2-C3

Temperature range: -20°C +180°C.

Vacuum: 10-3 torr.

Wafer_723000_con_V_BALL_sezionato_new_2

opzioni_V-ball

PositionPart nameMaterialN.° pieces
1BODYA351-CF8M1
2END CONNECTIONA479-TP316/A182-F3161
3BALLA351-CF8M1
4STEMA479-TP316/17-4-PH1
5BALL SEATRPTFE2
6BODY SEATPTFE1
7STEM SEATPTFE1
8ANTIFRICTION RINGTFM-MPTFE1
9O-RINGFKM2
10O-RINGFKM1
SIZEDNCODEDYZLACEØNBØN1B1PNKg
1"25723004 C106- C206- C306110854xM12487011936-F035,550-F057162,40
1"1/432723004 C107-C207-C3071301004xM16548210936-F035,550-F057163,50
1"1/240723004 C108-C208-C3081401104xM1663,593131150-F056,5--164,50
2"50723004 C110-C210-C3101551254xM1682101,513,51150-F056,570-F079166,70
2"1/265723004 C112-C212-C3121801454xM16103128,518,51470-F079--1610,90
3"80723004 C114-C214-C3141901608xM16122138181470-F079--1614,00
4"100723004 C118-C218-C3182201808xM1615215318,51770-F079--1620,90

Valpres - Wafer Ball Valves - Wafer PN16 - 724000

Temperature range: -20°C +180°C.

Vacuum: 10-3 torr.

PositionPart nameMaterialN.° pieces
1BODYA352-LCB1
2END CONNECTIONASTM A1051
3BALLA351-CF8/A479-TP3041
4BALL SEATTFM-MPTFE2
5BODY SEATPTFE1
6THRUST WASHERTFM-MPTFE1
7O-RINGFKM2
8STEMA479-TP316/17-4-PH1
9STEM SEATPTFE1
10O-RINGFKM1
SIZEDNCODEDYZLACEØNBØN1B1KvPNKg
1"2572400006110854XM124870119365,550764,5162,40
1"1/432724000071301004XM165482109365,5507103,8163,50
1"1/240724000081401104XM1663,5931311506,5--174164,50
2"50724000101551254XM1682101,513,511506,5709301,3166,70
2"1/265724000121801454XM16103128,515,514709--545,71610,90
3"80724000141901608XM161221381514709--872,51614,00
4"100724000182201808XM1615215318,517709--1363,31620,90

Available versions: ANSI150M: 724100; ANSI150U: 724101.

Valpres - Wafer Ball Valves - Wafer PN16 V-Ball - 724005 C1-C2-C3

Temperature range: -20°C +180°C.

Vacuum: 10-3 torr.


opzioni_V-ball

723000_leva_dead_man_diritta

PositionPart nameMaterialN.° pieces
1BODYA352-LCB1
2END CONNECTIONASTM A1051
3BALLA351-CF8M1
4STEMA479-TP316/17-4-PH1
5BALL SEATRPTFE2
6BODY SEATPTFE1
7STEM SEATPTFE1
8ANTIFRICTION RINGTFM-MPTFE1
9O-RINGFKM2
10O-RINGFKM1
SIZEDNCODEDYZLACEØNBØN1B1PNKg
1"25724005 C106- C206- C306110854xM12487011936-F035,550-F057162,40
1"1/432724005 C107-C207-C3071301004xM16548210936-F035,550-F057163,50
1"1/240724005 C108-C208-C3081401104xM1663,593131150-F056,5--164,50
2"50724005 C110-C210-C3101551254xM1682101,513,51150-F056,570-F079166,70
2"1/265724005 C112-C212-C3121801454xM16103128,518,51470-F079--1610,90
3"80724005 C114-C214-C3141901608xM16122138181470-F079--1614,00
4"100724005 C118-C218-C3182201808xM1615215318,51770-F079--1620,90

Certifications

ΑΤΕΧ  ΑΤΕΧ

  SIL 3  SIL 3
