Ball Valve - Type 36002 | Ibor Valves

Experience Superior Flow Control – Ball Valve - Type 36002 | Ibor Valves

When reliability and efficiency matter most, the Ball Valve - Type 36002 | Ibor Valves steps up to deliver outstanding performance. Crafted for industrial use, this valve is built to tackle demanding environments and ensure smooth, leak-free operation every time. Designed with precision and care, it offers peace of mind and dependability for all your flow control needs.

Key Benefits & Features of Ball Valve - Type 36002 | Ibor Valves

  • Robust Construction: Made from high-grade materials, this ball valve resists corrosion, pressure, and everyday wear. Its durability translates to fewer replacements and consistent performance over time.
  • Smooth Operation: The innovative ball mechanism ensures easy, on-the-spot opening and closing. This design minimizes friction, making it simple to operate even after years of use.
  • Leak-Proof Design: Precision engineering guarantees a tight seal, so you never have to worry about leaks disrupting your process or causing costly downtime.
  • Versatile Compatibility: Built to integrate seamlessly with most industrial pipe systems, the valve fits a range of applications, making it a flexible choice for many industries.
  • Low Maintenance: With fewer moving parts and a self-cleaning design, upkeep is kept to a minimum. Save time and money on maintenance without sacrificing reliability or safety.
  • Efficient Flow Control: The valve allows for full-bore passage, meaning liquids or gases flow with minimal resistance. Maximum efficiency, less energy loss.
  • Easy Installation: Clear connection points make for fast, straightforward installation, reducing setup times and simplifying changes or upgrades.

Whether you are controlling water, gas, or industrial fluids, the Ball Valve - Type 36002 | Ibor Valves ensures dependable performance with every turn. Its clear design and sturdy build make it the smart choice for demanding operations. If you are looking for a reliable, cost-effective solution that stands the test of time, look no further. Upgrade your system’s efficiency and safeguard your process with a valve you can trust.

Description

Seat design

  • Self-relieving seat (cavity relief)

Stem

  • Stem or bonnet extension
  • Design according to fugitive emissions
  • Locking device

Other

  • Drain plug

Connections

Flanged End: ASME B16.5 / GOST 12815-80 / EN 1092.1

Socket Weld End: ASME B16.11

**integral nipples and available

Butt Weld End: ASME B16.25

**integral nipples and available

Threaded NPT End: ASME B1.20.1

Threaded BSPP OR BSPT: BS21

Others

Design & Certification

Normative: ANSI / DIN

Design: API 6D / ISO 17292

Face to Face: ASME B16.10 / EN 558.1 Serie 27

Top Flange: ISO 5211

Press-Temp Ratings & Thickness: ASME B16.34

Test: API 6D / API 598 / BS 6755 Part 1

Pressure Equipment Directive: PED 2014/68/EU Mod. H1

Equipment Directive: ATEX 94/9/EC

Fire Safe: API 6FA / API 607 / ISO 10497-2

Fugitive Emissions: Class”A” acc.to ISO 15484-2

Safety integrity level: Sil 2 acc.to IEC 61508

Material: NACE MR0175 Lastest Edition

Certification:EN 10204 type 3.1, (3.2 upon request)
