Θερμοστατική βαλβίδα τρίοδη Clorius τύπος G3F

Η Θερμοστατική βαλβίδα τρίοδη G3F από την Clorius Controls είναι σχεδιασμένη για τη ρύθμιση συστημάτων ψύξης νερού και κυλινδρικών επενδύσεων εξαρτώμενων από το φορτίο (LDCL). Η βαλβίδα διαθέτει μαλακή έδραση που εξασφαλίζει στεγανότητα 99.99% μεταξύ των θυρών AB-B, προσφέροντας ενεργειακή εξοικονόμηση. Διατίθεται σε μεγέθη DN80 έως DN300, με ονομαστική πίεση PN16 για DN80-200 και PN10 για DN300/250-300. Κατασκευάζεται από ελατό χυτοσίδηρο, με εξαρτήματα από αλουμίνιο-μπρούντζο και ανοξείδωτο χάλυβα, και διαθέτει φλάντζες σύμφωνα με τα πρότυπα EN 1092-2, JIS B2210 10k και DIN 2633.


Τύπος : DN80-300 - Low Leakage
Τυποποίηση (Επιλογές)
  • DIN
  • JIS
Σύνδεση (Επιλογές)
  • Φλαντζωτή
Υλικό Κατασκευής (Επιλογές)
  • EN-GJS-400-15 (Nodular Cast Iron)
Ονομαστική Πίεση (Επιλογές)
  • PN 10
  • PN 16
  • PN 25
Ροή (Επιλογές)
  • Διαχωρισμού
  • Αναμείξεως

Τεχνικά Φυλλάδια / Οδηγίες Χρήσης / Λοιπά

Περιγραφή

Applications

Control valves type Low Leakage are designed for regulating of load dependant cylinder liner (LDCL), cooling water systems. Soft-seat makes the valve 99.99% tight between port AB-B for energy savings

GENERALLY

Sizes: DN80, 100, 125, 150, DN200/175, 200, 300/250, 300

Nom. pressure: PN16 - DN80-200 PN10 - DN300/250-300

Material: Nodular cast iron

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 JIS B2210 10k DIN 2633

Applications

Control valves type G3F are designed for regulating of water, lubricating oil and other liquid media and can be mounted in the pipe system as either mixing or diverting valves.  valves are used in conjunction with our temperature regulators for controlling industrial processes, district and central heating plants and marine installations.

GENERALLY

Sizes: DN80, 100, 125, 150

Nom. pressure: PN16

Material: Nodular cast iron

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 ANSI B16.5 Class 150 DIN 2633

Applications

Control valves type G3F are designed for hot water and hot oil systems and can be installed in pipe systems as mixing or diverting valves. The valves are used in conjunction with our temperature regulators for controlling industrial processes, district or central heating plants or marine installations.

GENERALLY

Sizes: DN20, 25, 32, 40, 50, 65

Nom. pressure: PN25

Material: Nodular cast iron

Material (components): Stainless steel

Flanges: EN 1092-2 DIN 2634
