Θερμοστατική βαλβίδα τρίοδη Clorius τύπος G3F-I

Η θερμοστατική βαλβίδα τρίοδη G3F-I από την Clorius Controls είναι σχεδιασμένη για τον έλεγχο συστημάτων ψύξης νερού και κυλινδρικών επενδύσεων εξαρτώμενων από το φορτίο (LDCL). Διαθέτει ανεστραμμένες θύρες για εφαρμογές με κοινή θύρα στην αριστερή πλευρά. Οι διαθέσιμες διαστάσεις κυμαίνονται από DN80 έως DN300, με ονομαστική πίεση PN10 για τις μεγαλύτερες διαστάσεις και PN16 για τις μικρότερες. Κατασκευάζεται από ελατό χυτοσίδηρο, με εξαρτήματα από αλουμίνιο-μπρούντζο και ανοξείδωτο χάλυβα. Οι φλάντζες συμμορφώνονται με τα πρότυπα EN 1092-2, JIS B 2210 10K και DIN 2633.


Τύπος : DN80-300
Τυποποίηση (Επιλογές)
  • DIN
  • JIS
Σύνδεση (Επιλογές)
  • Φλαντζωτή
Υλικό Κατασκευής (Επιλογές)
  • EN-GJS-400-15 (Nodular Cast Iron)
Ονομαστική Πίεση (Επιλογές)
  • PN 10
  • PN 16
Ροή (Επιλογές)
  • Διαχωρισμού
  • Αναμείξεως

Τεχνικά Φυλλάδια / Οδηγίες Χρήσης / Λοιπά

Περιγραφή

Applications

Control valves type Low Leakage are designed for regulating of load dependant cylinder liner (LDCL), cooling water systems. The valve is designed with inverted ports for application with common port on the left side.

GENERALLY

Sizes: DN80, 100, 125, 150, DN200/175, 200, 200/250, 300

Nom. pressure: PN10 - 300/250-300 PN16 - 80-200

Material: Nodular cast iron

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 JIS B 2210 10K DIN 2633

Applications

Control valves type Low Leakage are designed for regulating of load dependant cylinder liner (LDCL), cooling water systems. The valve is designed with inverted ports for application with common port on the left side.

GENERALLY

Sizes: DN80, 100, 125, 150, DN200/175, 200, 200/250, 300

Nom. pressure: PN10 - 300/250-300 PN16 - 80-200

Material: Nodular cast iron

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 JIS B 2210 10K DIN 2633

Applications

Control valves type G3F-I are designed for regulating of water, lubricating oil and other liquid media and can be mounted in the pipe system as either mixing or diverting valves.  The valves are used in conjunction with our temperature regulators for controlling industrial processes, district and central heating plants and marine installations.

GENERALLY

Sizes: DN80, 100, 125, 150

Nom. pressure: PN16

Material: Nodular cast iron

Material (components): Alu. bronze & Stainless steel

Flanges: EN 1092-2 ANSI B16.5 Class 150 DIN 2633
