The BLU ZAC SACO is a compact heat exchanger designed for cooling or heating process sample fluids. In boiler houses, it is primarily used to cool boiler water, condensate, or hot water samples prior to conductivity, pH measurement, or chemical analysis. Operation is based on a helical coil immersed in a small vessel with a heating or cooling medium.
The sample cooler consists of a body, internal coil, cover, gasket, bolts, and nuts. BLU ZAC specifies typical design and fabrication in accordance with ASME VIII Div.1 and ASME B16.34.
Available configurations:
Material options include:
Suitable for sampling points in steam boilers, condensate lines, feedwater, and auxiliary process circuits. Material selection should consider pressure, temperature, water chemistry, corrosivity, and compatibility with existing piping.
Annual maintenance and monthly inspection/cleaning are recommended where accessible. For threaded cover versions, maintenance includes line isolation, cover removal, coil cleaning, inspection for wear, gasket replacement, and leak testing on restart.
SAMPLE COOLER
Heat exchangers are generally used as fluid coolers/heaters.
The design involves a small amount of helicoidal spiral piping immersed in a small cask filled with of a hot/cold liquid; according to the principle of heat exchange the piping absorbs/releases the temperature of the liquid in which it is immersed, allowing the plant’s technicians to bring the fluid to the required temperature.
| SIZES |
|---|
| from 3/8” to 1” |
| CONNECTIONS | ||
|---|---|---|
| Buttweld | BW | ANSI B16.25 |
| Flanged | FLG | ANSI B16.5 |
