Ultimate Safety and Convenience: Hand-held eye shower with two spray head - PremiumLine -BR 719 020 | B-Safety

Stay prepared for any industrial emergency with the Hand-held eye shower with two spray head - PremiumLine -BR 719 020 | B-Safety, a reliable and efficient solution for immediate eye rinsing. This high-quality device is designed to deliver outstanding performance, ensuring rapid and gentle decontamination when every second counts. Its robust design and advanced features make it an essential addition to any industrial workspace, laboratory, or chemical area.

Features & Benefits of the Hand-held eye shower with two spray head - PremiumLine -BR 719 020 | B-Safety

  • Dual Spray Heads for Maximum Coverage: The twin spray nozzles provide a soft, even flow of water to both eyes, covering a larger area for thorough rinsing and minimizing discomfort during use.
  • Flexible Hand-held Design: Lightweight and ergonomically shaped, it allows quick, direct use so users can easily target affected areas. The flexible hose gives freedom of movement in tight spaces.
  • Durable Premium Construction: Made from robust, corrosion-resistant materials that stand up to challenging industrial conditions, ensuring long-term reliability and low maintenance.
  • Intuitive Operation: The user-friendly trigger mechanism starts water flow instantly for fast response in emergencies, reducing panic and confusion.
  • Adjustable Wall Mount: The included holder offers convenient, secure storage and quick accessibility. The mount can be installed wherever you need fast emergency access.
  • Gentle, Aerated Water Stream: Special spray heads ensure a soft, bubble-infused water flow, effectively rinsing eyes without causing additional irritation.
  • Compliance Ready: This eye shower is built according to international safety standards, meeting strict industry requirements for workplace safety.

The Hand-held eye shower with two spray head - PremiumLine -BR 719 020 | B-Safety is a wise investment for any industrial setting. It empowers staff to act quickly and effectively in the event of accidental splashes or contamination, helping to prevent long-term eye injuries. Simple to operate, dependable, and designed for tough environments, it provides peace of mind for workers and managers alike.

Choose the Hand-held eye shower with two spray head - PremiumLine -BR 719 020 | B-Safety for a safer, more secure workplace where every precaution matters.

Datasheet and documents

Description

Technical Specifications

  • Material: Stainless steel
  • Surface: polished
  • Dimensions (H x W): 260 x 145 mm
  • Hose-Length: 1500 mm
  • Operating pressure: 2.5 to 5 bar
  • Flow rate: 14 litres / minute
  • Water inlet: ½” female

Norms / Approvals

  • EN 15154-2:2006
  • ANSI Z358.1-2014
  • DIN-DVGW, NW-0417CL0263
  • GOST-R, Certificate-No. 0615463 0615463

Product description

The hand-held eye shower is equipped with two B-SAFETY high-performance shower heads, which not only meet the requirements of EN 15154-2:2006 and ANSI Z358.1-2014, but also ensure that the water is distributed over a large area. This also takes care of the regions around the eyes and eyes can be positioned in the water jet without problems. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye.

With the enclosed table mounting accessory, the hand-held eye shower can be mounted on the table. The robust stainless steel-coated hose in 1.5 meter length ensures good usability of the shower. The correct spray height and a standard-compliant spray pattern are achieved by the integrated flow regulator, regardless of the water pressure present. The backflow preventer built into the handle of the shower provides additional protection of the drinking water network.

DVGW
ISO9001_D_72

Technical Description

  • water-bearing parts made of stainless steel
  • Handle with large, adjusting push lever made of stainless steel, polished, valve not self-closing
  • high-performance spray heads made of stainless for large-scale dispersion of water, polished, with plastic spray plate, low calcification, incl. rubber sleeves and sealed dust caps with folding mechanism, mounted over distribution fork made of polished stainless steel
  • integrated automatic flow regulator 14 litres / minute for a standard-compliant blasting pattern at a specified working range of 2.5 to 5 bar flow pressure
  • integrated backflow preventer to protect the drinking water
  • stainless steel covered hose, length 1.5 meter, water inlet ½” female, DIN-DVGW tested and certificated
  • table mounting accessories M28x1,5x80mm made of stainless steel, incl. fastening-parts kit with nut M28x1,5mm and 2 screws M5 for mounting difficult to access, chrome-plated rosette, sealing to table surface with O-Ring
  • sign for eye shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 100 x 100 mm, viewing distance 10 metre
  • Mounting height 680 mm (± 200 mm)
  • according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
  • according to ANSI Z358.1-2014 and EN 15154-2:2006
  • DIN-DVGW tested and certificated

Certification

DVGW    ISO9001_D_72.png
