Features and Benefits of the Hand-held Eye Shower with Two Spray Head 45° - ClassicLine - BR 714 020 | B-Safety

Ensure maximum safety and protection in the workplace with the Hand-held Eye Shower with Two Spray Head 45° - ClassicLine - BR 714 020 | B-Safety. Specially crafted for industrial settings, this reliable eye wash station delivers quick and effective relief in case of hazardous splashes or accidents. Engineered for comfort and efficiency, it combines advanced technology with practical design to deliver peace of mind on your work site.

  • Dual 45° Spray Heads: The innovative double spray heads are angled at 45°, ensuring a gentle yet thorough rinse over a wide area. This directs water precisely for full coverage, helping to flush both eyes evenly in an emergency.
  • Hand-held Convenience: Its ergonomic design allows you to operate the shower with one hand, giving you mobility and control when time matters most.
  • High-Performance Flow: Delivers optimal water pressure, providing a soft but effective stream that is suitable for sensitive eyes, rinsing out contaminants quickly while avoiding further irritation.
  • Industrial-Grade Durability: Made from robust materials, this unit is designed to withstand heavy, everyday use in demanding environments such as laboratories, factories, and workshops.
  • Flexible and Easy Installation: The compact form factor and flexible hose make installation hassle-free, fitting efficiently in various workplace setups and saving valuable space.
  • Low-Maintenance Operation: Easy to clean and maintain, ensuring reliable performance whenever you need it most.

With the Hand-held Eye Shower with Two Spray Head 45° - ClassicLine - BR 714 020 | B-Safety, every detail is designed to provide rapid response and effective decontamination. Whether you’re dealing with chemicals, debris, or other irritants, this eye shower offers peace of mind through instant access and reliable performance.

Be prepared and protect your team with the essential solution trusted by industrial professionals. Invest in workplace safety and ensure quick action is always within reach.

Datasheet and documents

Description

Technical Specifications

  • Material: brass, plastic
  • Color: grey, green, orange
  • Dimensions (H x W): 310 x 145 mm
  • Hose-Length: 1500 mm
  • Operating pressure: 2.5 to 5 bar
  • Flow rate: 14 litres / minute
  • Water inlet: ½” female

Norms / Approvals

  • EN 15154-2:2006
  • ANSI Z358.1-2014
  • DIN-DVGW, NW-0417CL0263
  • GOST-R, Certificate-No. 0615463 0615463

Product description

The hand-held eye shower is equipped with two B-SAFETY high-performance shower heads, which not only meet the requirements of EN 15154-2:2006 and ANSI Z358.1-2014, but also ensure that the water is distributed over a large area. This also takes care of the regions around the eyes and eyes can be positioned in the water jet without problems. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye.

With the enclosed table mounting accessory, the hand-held eye shower can be mounted on the table. The robust stainless steel-coated hose in 1.5 meter length ensures good usability of the shower. The correct spray height and a standard-compliant spray pattern are achieved by the integrated flow regulator, regardless of the water pressure present. The backflow preventer built into the handle of the shower provides additional protection of the drinking water network.

DVGW
ISO9001_D_72

Technical Description

  • B-SAFETY ClassicLine hand-held eye shower with two spray heads 45°, table mounted
  • ergonomically shaped handle with integrated, adjusting activation made of plastics, valve not self-closing
  • high-performance spray heads for large-scale dispersion of water, 45° angled, with plastic spray plate, low calcification, incl. with rubber sleeves and sealed dust caps with folding mechanism, mounted over distributor fork
  • integrated automatic flow regulator 14 litres / minute for a standard-compliant blasting pattern at a specified working range of 2.5 to 5 bar flow pressure
  • integrated backflow preventer to protect the drinking water
  • stainless steel covered hose, length 1.5 meter, water inlet ½” female, DIN-DVGW tested and certificated
  • table mounting accessories M28x1,5x80mm made of stainless steel, incl. fastening-parts kit with nut M28x1,5mm and 2 screws M5 for mounting difficult to access, rosette plastic, green, sealing to table surface with O-Ring
  • sign for eye shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 100 x 100 mm, viewing distance 10 metre
  • Mounting height 700 mm (± 200 mm)
  • according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
  • according to ANSI Z358.1-2014 and EN 15154-2:2006
  • DIN-DVGW tested and certificated
