Hand-held eye shower with two spray head 45° - ClassicLine - BR 714 025 | B-Safety: Safety and Comfort in Industrial Settings

The Hand-held eye shower with two spray head 45° - ClassicLine - BR 714 025 | B-Safety is thoughtfully engineered to deliver instant eye relief exactly when and where it’s needed most. Designed for busy industrial environments, this robust eye shower puts safety and usability at the forefront, making it an essential tool for any workplace where eye protection is critical.

Features & Benefits of Hand-held eye shower with two spray head 45° - ClassicLine - BR 714 025 | B-Safety

Dual Spray Heads at 45°: The twin spray nozzles are strategically set at a 45-degree angle, ensuring thorough rinsing of both eyes simultaneously. This allows for immediate and even coverage, effectively washing away hazardous particles or chemicals.
Flexible Hand-held Design: The easy-grip handle means the shower is always within reach, making it simple to direct the water stream exactly where it's needed. Its portable setup provides flexibility—perfect for quickly responding to accidents with precision.
Reliable Water Flow: With a steady and gentle water stream, this eye shower secures a soothing yet effective rinse. It’s designed to clean the eyes without causing additional irritation, offering peace of mind in high-risk settings.
Built for Industrial Use: Made with premium materials, the ClassicLine - BR 714 025 is tough enough to endure daily wear and tear. Its resilience makes it ideal for factories, laboratories, and workshops, where durability can’t be compromised.
Simple Activation: Quick-start operation ensures immediate use in emergencies. The intuitive design reduces hesitation, delivering fast relief when every second matters.

By integrating the Hand-held eye shower with two spray head 45° - ClassicLine - BR 714 025 | B-Safety into your workplace, you demonstrate a commitment to employee well-being. Its practical functionality ensures that anyone—regardless of experience—can confidently respond to eye exposure incidents. The user-friendly, robust construction means less downtime and more protection, enhancing safety standards across your site.

Invest in reliability and instant protection with this indispensable safety solution. Stay prepared, minimize risk, and support workplace health with the Hand-held eye shower with two spray head 45° - ClassicLine - BR 714 025 | B-Safety.

Datasheet and documents

Description

Technical Specifications

Material: brass, plastic
Color: grey, green
Dimensions (H x W): 310 x 145 mm
Hose-Length: 1500 mm
Operating pressure: 2.5 to 5 bar
Flow rate: 14 litres / minute
Water inlet: ½” female

Norms / Approvals

EN 15154-2:2006
ANSI Z358.1-2014
DIN-DVGW, NW-0417CL0263
GOST-R, Certificate-No. 0615463 0615463

Product description

The hand-held eye shower is equipped with two B-SAFETY high-performance shower heads, which not only meet the requirements of EN 15154-2:2006 and ANSI Z358.1-2014, but also ensure that the water is distributed over a large area. This also takes care of the regions around the eyes and eyes can be positioned in the water jet without problems. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye.

With the enclosed B-SAFETY combination bracket, the hand-held eye shower can be mounted on the wall or also on the table. The robust stainless steel-coated hose in 1.5 meter length ensures good usability of the shower. The correct spray height and a standard-compliant spray pattern are achieved by the integrated flow regulator, regardless of the water pressure present. The backflow preventer built into the handle of the shower provides additional protection of the drinking water network.

Technical Description

B-SAFETY ClassicLine hand-held eye shower with two spray heads 45°, wall and table mounted

ergonomically shaped handle with integrated, adjusting activation made of plastics, valve not self-closing
high-performance spray heads for large-scale dispersion of water, 45° angled, with plastic spray plate, low calcification, incl. with rubber sleeves and sealed dust caps with folding mechanism, mounted over distributor fork
integrated automatic flow regulator 14 litres / minute for a standard-compliant blasting pattern at a specified working range of 2.5 to 5 bar flow pressure
integrated backflow preventer to protect the drinking water
stainless steel covered hose, length 1.5 meter, water inlet ½” female, DIN-DVGW tested and certificated
robust table and wall mounting bracket with positioning of the shower, incl. fastening-parts kit with nut M28x1,5mm and 2 screws M5 for mounting difficult to access, sealing to wall/table surface by means of special seal
sign for eye shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 100 x 100 mm, viewing distance 10 metre
Mounting height 700 mm (± 200 mm)
according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
according to ANSI Z358.1-2014 and EN 15154-2:2006
DIN-DVGW tested and certificated

Certification

DVGW
