Adler RT7 4-Way Ball Valve

The Adler RT7 is a four-way ball valve with an X-port ball configuration, designed for flow path switching in industrial process circuits. The compact wafer type body is machined from round bar, with threaded connections per ISO 7-1 Rp / GAS or NPT to ASME B1.20.1. Available in sizes 1/4" to 2" and pressure classes PN25 to PN63.

Technical Data

  • Design: 4-way ball valve, X-port ball
  • Standards: DIN 3202 M3, ASME B16.34, ISO 14313
  • Full bore per ISO 14313
  • Body materials: ASTM A105 or ASTM A479 316/316L
  • Ball: AISI 304/304L, CF8, 316/316L, or CF8M
  • Seats: PTFE, optional RPTFE
  • Stem sealing: PTFE / graphite chevron rings
  • Stem O-ring: FKM / Viton on request
  • Top flange: ISO 5211
  • Stem: anti blow-out
  • Antistatic device: BS 5146
  • Tested 100% with air, submerged, at 100 psi.

Operational Use

The X-port ball enables multiple flow path combinations between four ports. Typical applications include flow distribution, line switching, bypass circuits, tank selection, or replacing multiple two- or three-way valves in process systems. Flow path geometry must be specified in P&ID, as the four-way configuration can create unintended port communication if not properly oriented.

Certifications & Options

On request: PED 2014/68/EU, ATEX 2014/34/EU, fire-safe ISO 10497 / API 607 / BS6755, ISO 15848 fugitive emission class A, SIL 3 capable, oxygen cleaning per ISO 23208, cryogenic execution, stem extension, pneumatic or electric actuator, gear operator, limit switches, and solenoid valves.

FAQ

When is a four-way valve selected over a three-way?
When four branch circuits must be managed with a single switching device.

What should be checked before selection?
X-port flow pattern, DN, PN, ISO or NPT thread, body material, PTFE/RPTFE seat, actuator torque, and requirements for ATEX, fire-safe, or ISO 15848 compliance.

Standard (Options)
  • DIN
Connection (Options)
  • BSP
Material (Options)
  • ASTM A105
  • ASTM A479 Type 316
Pressure Rating (Options)
  • PN 25
  • PN 63
Seat (Options)
  • PTFE

Datasheet and documents

Description

Four way 90° ball valve “wafer type”, manufactured from round bar, according to DIN 3230 M3; ; ASME B16.34; ISO 14313.

Available size from DN ¼” to 2” in carbon steel and in stainless steel.

Rating PN 25÷63.

Thread available ISO 7RP (GAS); ASME B1.20.1 (NPT)

With “X” port ball type.

Chevron ring on stem.

On request:

– with o’ring on stem (patent n°00219688).

– fire-safe execution according to ISO 10497 API 607

– fire-safe execution according to BS6755 API 607/6FA (patent n° 00219617).

– according to  PED 14/68/UE directive

– according to ATEX 14/34/UE directive

– degreased according to ISO 23208 for oxigen serivce

– certified in safety  system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848

Standard productions

anti blow out proof stem

construction and marking BS 5351

carbon steel valves painted with first coat of epoxy-polyammidic RAL 5012 35 microns

antistatic device BS 5146 / 74

top flange ISO 5211

all valves 100% air tested under water at 100 psi

On demand accessories

PTFE seats filled glass – carbon – S.S. – bronze, metal core

cryogenic valves

stem extention

oval handle

pneumatic actuator double/single acting

electric motor

manual gear box

electric-pneumatic limit switches/solenoid valves

Certificates

– certified in safety  system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848

– ISO 9001 by L.R.

– PED DIR. 2014/68/UE by L.R.

– ATEX DIR. 2014/34/UE by B.V.

– FIRE SAFE EXECUTION BS6755/API 607 by L.R.

– FIRE SAFE TESTED ISO 10497 by L.R.

– ISO 15848 by TÜV

– ANTISTATIC DEVICE by L.R.

– EAC CERTIFICATION by B.V.
