Ball Valve wafer - Type FC2 | ADLER: Advanced Flow Control for Industrial Reliability

The Ball Valve wafer - Type FC2 | ADLER delivers exceptional performance where it counts—industries demanding safe, consistent, and efficient fluid handling. Designed to fit snugly between flanges, this space-saving valve offers a smart solution to flow control in tight spaces. Its robust construction and innovative features make it a trustworthy component for a wide range of applications.

Features & Benefits of Ball Valve wafer - Type FC2 | ADLER

  • Compact Design: The wafer-style body slips effortlessly between pipeline flanges, saving valuable space without compromising strength or performance.
  • Reliable Sealing: Engineered for a tight seal, this valve prevents leaks and ensures safe operation, even under demanding conditions.
  • Easy Operation: The simple quarter-turn handle lets operators open or close the valve quickly, promoting efficiency and reducing downtime.
  • Durable Materials: Crafted from high-quality metals and seals, the Ball Valve wafer - Type FC2 | ADLER can withstand high pressures and various industrial fluids, ensuring a long service life.
  • Low Maintenance: Fewer moving parts mean less wear and fewer repairs, keeping ongoing costs low and reliability high.
  • Versatility: Suitable for a broad range of industrial pipelines, this valve adapts to many fluids and process requirements.

The Ball Valve wafer - Type FC2 | ADLER stands out for its clever engineering. The unique wafer shape makes installation simpler and reduces the weight carried by the pipeline, making it easier to mount and maintain. The powerful sealing mechanism means you avoid costly product losses and protect both workers and equipment from leaks.

This ball valve brings efficiency and safety together. The user-friendly handle ensures quick responses in critical situations, while the sturdy body resists corrosion and pressure. Whether controlling water, chemicals, or other industrial fluids, it offers a high degree of trust and performance.

Choose the Ball Valve wafer - Type FC2 | ADLER for a compact, durable, and easy-to-use valve that keeps your process running smoothly. Experience precision control, longer lifespan, and ultimate peace of mind in every operation.

Standard (Options)
  • DIN
  • ANSI
Connection (Options)
  • Flanged (Wafer)
Material (Options)
  • ASTM A105N
  • ASTM A479 Type 304
  • ASTM A479 Type 316
Pressure Rating (Options)
  • PN 63
  • PN 100
  • PN 160
Seat (Options)
  • PTFE

Datasheet and documents

Description

Ball valve “wafer type”, full bore, manufactured from round bar, construction in according to EN 12516.2; ASME B16.34; ISO 14313; EN 1092-1; EN 1759-1; ASME B16.5; ANSI B1.1; ISO 14313.

Available size from DN 10 to DN 40 in carbon steel, in stainless steel and special steel

Rating PN 63 – 100 – 160 / ANSI 600 / ANSI 900  / ANSI 1500.

Double seals on body/insert junction

Chevron ring on stem.

On request :

– with o’ring on stem (patent n°00219688).

– fire-safe execution according to ISO 10497 API 607

– fire safe execution BS6755 API 607/6FA (patent n° 00219617)

– cryogenic execution ISO 28921

– according to PED 14/68/UE directive

– according to TPED 2010/35/UE directive

– according to ATEX14/34/UE directive

– degrease according to ISO 23208 oxige service

– certified in safety system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848.

Standard productions

anti blow out proof stem

construction and marking BS 5351

carbon steel valves painted with first coat of epoxy-polyammidic RAL 5012 35 microns

antistatic device BS5146/74

top flange ISO 5211

all valves 100% air tested under water at 100 psi

On demand accessories

PTFE / glass renforced PTFE half shell

PTFE seats filled glass – carbon – S.S. – bronze, metal core

stem extension

cryogenic extension

oval handle

pneumatic actuator double/single acting

electric actuator

manual gear box

pneumatic/electro-pneumatic positioner

Certificates

– certified in safety system S.I.L. 3.

– certified for fugitive emission in class “A” ISO 15848.

– ISO 9001 by L.R.

– PED DIR. 2014/68/UE by L.R.

– ATEX DIR. 2014/34/UE by B.V.

– FIRE SAFE EXECUTION BS6755/API 607 by L.R.

– FIRE SAFE TESTED ISO 10497 by L.R.

– ISO 15848 by TÜV

– ANTISTATIC DEVICE by L.R.

– EAC CERTIFICATION by B.V.
