Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki

Name: Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki
Brand: Miyawaki
SKU: Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki

Reliable Performance with Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki

The Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki is crafted for precision, reliability, and long-term use in demanding industrial steam systems. This advanced valve ensures consistent steam pressure, helping to safeguard equipment and improve process efficiency. Whether for factories, processing plants, or heating systems, it’s designed to deliver stable operation under varying conditions.

Features & Benefits of Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki

Consistent Pressure Control: Automatically maintains the set downstream pressure, protecting sensitive devices and reducing the risk of system failure.
Direct Acting Mechanism: Responds instantly to pressure fluctuations, ensuring your steam output stays constant and safe.
Compact Design: Built to fit neatly into existing systems with minimal space requirements, enabling easy installation and maintenance.
Durable Construction: Engineered with high-quality materials to withstand the rigors of continuous industrial operation and extreme steam conditions.
Energy Efficiency: By maintaining optimal pressure, it reduces unnecessary steam loss, lowering energy consumption and operational costs.
Simple Adjustment: The pressure setting can be changed quickly, making it easy to adapt for different processes or system demands.

The REH20-M model is specifically made for steam applications, ensuring your steam-powered equipment runs smoothly. Its direct acting system simplifies the control process, with no need for complex auxiliaries. This means fewer parts, less maintenance, and less downtime.

This valve supports a wide range of industrial applications, from food processing to textile production, where steady steam pressure is crucial. Its reliability helps you meet safety standards and boosts productivity by minimizing interruptions.

Choose the Pressure reducing valve - Direct Acting for steam - REH20-M | Miyawaki for proven performance, straightforward operation, robust safety, and energy savings—ensuring your steam system operates at its best every day.

Standard (Options)

Connection (Options)

Flanged

Material (Options)

1.7357
Cast Steel
GS 17 CrMo 55

Pressure Rating (Options)

PN 16
PN 25
PN 63
PN 100

Description

Features

Self acting pressure reducing valve for steam

This valve reduces the steam supply pressure to a defined outlet pressure and keeps it steady, even under downstream fluctuations . The valves needs no seperate energy source.

Wide range of pressure reduction

Due to carfefully selected springs an outstanding reduction ratio of 25:1 is achieved.

Superb durability

Highly durable and carefully selected components, a 360° free rotating, conical plug and the lack of a sensitive diaphragm ensure outstanding lifetime of this valve.

Operating features of direct acting pressure reducing valves

Pressure changes on the downstream side are detected in the detection chamber, and the degree of opening of the valve is directly adjusted to keep the pressure on the downstream side at set pressure.

Diaphram free design

The valve operates with an O-ring sealing and a piston design. Due to this design, no daiphragm and no external sensing line is required.

Options available

- additional pressure gauges

- tailored connections for special applications

- softsealing for leakage class VI

Typical applications

Perfect for all applications with medium to high steam flow or high reduction. In particuliar power plants, chemical and petrochemical process applications, ships, food and beverage plants, and other similar installations of of compact steam equipment.

Dimensions/Weight

Size (DN)	Dimensions (mm)			Kvs Value
Size (DN)	L	H	h	Kvs Value
15	210	410	82	1,8
20	230		66	3,2
25	230		66	5,0
32	260		81	7,9
40	260		83	13,0
50	300	586	100	20,0
65	340	615	113	34,0
80	380	733	140	51,0
100	430	762	154	80,0

Specifications

Body Material

Cast steel

G17CrMo 5-5 (1.7357)

Body design conditions

	PN63	PN100
Max. design pressure (MPa) PMA	6,3	10,0
Max. design temperature (℃) TMA	530	530
Max. operating pressure (MPa) PMO	5,7	8,4
Max. operating temperature (℃) TMO	530	530

Pressure - Temperature rating

PN	Temperature ℃
	-10･･･+50	100	150	200	250	300	350
	Pressure MPa
PN16	1,6	1,6	1,6	1,5	1,4	1,3	1,1
PN25	2,5	2,5	2,4	2,3	2,2	2,0	1,8

Secondary pressure ranges

Secondary pressure range	DN15-DN40	DN50	DN65	DN80	DN100	DN125-DN200
MPa	Spring number per size
0,05-0,1	9	28	27	38	37	On request
0,1-0,16	8	27	26	37	36
0,16-0,25	7	26	25	36	35
0,25-0,4	6	25	24	35	34
0,4-0,63	5	24	23	34	33
0,63-1,0	4	23	22	33	32
1,0-1,6	3	22	21	32	32

Secondary pressure ranges higher than 1,6 MPa and lower than 0,05 MPa on request available.
