Pressure or Vacuum Line Valve KITO F30.1N

The KITO VD/TA-1, series F30.1N, is a self-actuated line valve designed for tank or vessel breathing applications, operating as either a pressure relief or vacuum relief valve depending on installation orientation. Primarily used in piping systems, it can also serve as a non-return safety device or overflow valve in process lines.

Set Pressure Range

The F30.1N covers higher opening pressures than the F30N variant. Available settings:

• DN 25 to DN 100: above 200 up to 350 mbar
• DN 125 to DN 150: above 150 mbar
• Lower set pressures correspond to F30N type
• Higher settings require technical application review

Dimensions and Connections

Series covers DN 25–40 with PN 40 and DN 50–150 with PN 16. ASME equivalents: 1" to 6". Face-to-face length (C) can be customized for retrofit or limited pipe runs.

Materials and Sealing

Standard construction: carbon steel body/cover, optional stainless steel 1.4571. Seat, spindle, and spring components in stainless steel 1.4571. Spring-loaded pallet, metal-to-metal seat. Gasket: HD 3822 standard, PTFE optional.

Standards

• Flanges: EN 1092-1 Type A
• Optional: ASME B16.5 Class 150 RF
• Supplied without EC certificate or CE marking

Typical Applications

• Tank breathing lines with elevated opening pressures
• Overpressure or vacuum protection for vessels
• Process vent, inert gas, or vapor lines
• Check valve function in low-pressure networks
• Overflow or pressure equalization in closed systems

FAQ

When is F30.1N selected over F30N?
When the required opening pressure or vacuum exceeds the F30N range.

Is this a combined pressure/vacuum valve?
No. The same construction is used for either pressure or vacuum service, depending on installation direction.
