Adler FX1 Spherical Ball Valve with Heating Jacket

The Adler FX1 is a full bore wafer-type ball valve equipped with a heating jacket. Based on the FA1 series, it is designed for process lines where the medium must be maintained above its solidification point within the valve body—typical for resins, waxes, oils, bitumen, polymers, or crystallizing chemicals.

Technical Data

  • Type: Wafer ball valve, full bore
  • Pressure: PN10–PN40 or ANSI 150–300
  • Flanges: EN 1092-1 or ANSI B16.5
  • Body: ASTM A105, ASTM A479 304/304L or 316/316L
  • Ball: ASTM A479 304/304L or 316/316L, CF8 / CF8M
  • Seats: PTFE + 15% glass fibre
  • Stem sealing: PTFE / graphite chevron rings
  • O-ring: FKM / Viton
  • Top flange: ISO 5211
  • Max heating jacket pressure: 10 bar

Construction and Certifications

Manufactured in accordance with BS EN 12516-2, ANSI B16.34, and ISO 14313. Available with PED 2014/68/EU, ATEX 2014/34/EU, fire-safe BS6755/API 607, ISO 10497, ISO 15848, antistatic device, and SIL 3 capable for automated valves.

Operational Use

The heating jacket reduces the risk of solidification in the ball cavity and seat area. Selection must consider product melting point, jacket pressure, line insulation, and residence time.

Automation

The ISO 5211 flange supports pneumatic (single/double acting), electric actuators, manual gearboxes, or positioners. Torque selection depends on DN, pressure, temperature, and seat material.

FAQ

When is FX1 selected?
When a compact wafer flanged valve with body heat retention is required.

What should be checked before specification?
DN, PN/Class, body material, heating medium, jacket pressure (10 bar), seat material, and ATEX/fire-safe/fugitive emissions requirements.

Standard (Options)
  • DIN
  • ANSI
Connection (Options)
  • Flanged (Wafer)
Material (Options)
  • ASTM A105
  • ASTM A479 Type 304
  • ASTM A479 Type 304L
  • ASTM A479 Type 316
  • ASTM A479 Type 316L
Pressure Rating (Options)
  • PN 16
  • PN 25
  • PN 40
Seat (Options)
  • PTFE + 15 % G.F

Datasheet and documents

Description

Ball valve with heating jacket made in carbon steel or stainless steel

Flanged, threaded or welding ends

FX1 type made from FA1 ball valve type

Standard productions

maximum pressure of heating jacket 10 bar

anti blow out proof stem

construction and marking BS 5351

carbon steel valves painted with first coat of epoxy-

polyammidic RAL 5012 35 microns

antistatic device

top flange ISO 5211

all valves 100% air tested under water at 100 psi

On demand accessories

PTFE / glass reenforced PTFE half shell

PTFE seats filled glass – carbon – S.S. – bronze, metal core

stem extension

pneumatic actuator double/single acting

electric  actuator

manual gear box

pneumatic / electro-pneumatic positioner

Certificates

ISO 9001 by L.R.

PED DIR. 2014/68/UE by L.R.

ATEX DIR. 2014/34/UE by B.V.

FIRE SAFE EXECUTION BS6755/API 607 by L.R.

FIRE SAFE TESTED ISO 10497 by L.R.

ISO 15848 by TÜV

ANTISTATIC DEVICE by L.R.

EAC CERTIFICATION by B.V.
