Hand-held eye shower with one spray head - PremiumLine - BR 718 020 | B-Safety

Hand-held eye shower with one spray head - PremiumLine - BR 718 020 | B-Safety: Reliable Protection for Industrial Safety

Introducing the Hand-held eye shower with one spray head - PremiumLine - BR 718 020 | B-Safety—the essential safety device designed to offer immediate eye protection in challenging industrial environments. Built with durability and convenience in mind, this hand-held eye shower ensures that you have fast access to effective eye washing when every second counts. Choose peace of mind in your workspace with this premium safety solution.

Features and Benefits of Hand-held eye shower with one spray head - PremiumLine - BR 718 020 | B-Safety

  • Single Spray Head Design: The focused spray head delivers a gentle, wide stream, easily targeting the eye area for thorough rinsing. This design helps remove harmful particles quickly and comfortably.
  • Hand-held Flexibility: The compact, lightweight handle allows for precise control and easy maneuvering, making it easy to position the spray exactly where it's needed for effective cleansing.
  • PremiumLine Quality: Constructed with robust, high-quality materials, this eye shower withstands frequent use and harsh industrial conditions, giving you a long-lasting safety tool you can rely on.
  • Immediate Response: Instantly available in emergency situations, the hand-held operation ensures you can start rinsing eyes right away, reducing the risk of chemical or dust damage.
  • Effortless Installation: Designed for simple connection to existing water supplies, installation is quick and straightforward, making it a fantastic addition to any safety station.
  • Easy Maintenance: The smooth surfaces and minimal parts make cleaning and maintaining the device hassle-free, ensuring hygiene standards are always met.

This eye shower is crafted for the demanding needs of industrial settings, such as laboratories, factories, or workshops where hazardous substances are handled. Its intuitive operation makes it accessible, even for users with minimal training. The single spray head minimizes water waste while maximizing efficiency, protecting users without causing discomfort.

With the Hand-held eye shower with one spray head - PremiumLine - BR 718 020 | B-Safety, you are investing in a reliable safety tool that puts user well-being first. Experience peace of mind, knowing you are prepared for eye emergencies at any moment.

Datasheet and documents

Description

Technical Specifications

  • Material: Stainless steel
  • Surface: polished
  • Dimensions (H x W): 210 x 65 mm
  • Hose-Length: 1500 mm
  • Operating pressure: 1.5 to 5 bar
  • Flow rate: 7 l/min
  • Water inlet: ½” female

Norms / Approvals

  • EN 15154-2:2006
  • ANSI Z358.1-2014
  • DIN-DVGW, NW-0417CL0263
  • GOST-R, Certificate-No. 0615463 0615463

Product description

The hand-held eye shower is equipped with the B-SAFETY high-performance spray head, which not only meets the requirements of EN 15154-2:2006 and ANSI Z358.1-2014, but also ensure that the water is distributed over a large area. This also takes care of the regions around the eyes and eyes can be positioned in the water jet without problems. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye. The restricted, even and, most important of all, soft water jet has been optimized for rinsing chemicals out of the eye.

With the enclosed table mounting accessory, the hand-held eye shower can be mounted on the table. The robust stainless steel-coated hose in 1.5 meter length ensures good usability of the shower. The correct spray height and a standard-compliant spray pattern are achieved by the integrated flow regulator, regardless of the water pressure present. The backflow preventer built into the handle of the shower provides additional protection of the drinking water network.

DVGW
ISO9001_D_72

Technical Description

  • water-bearing parts made of stainless steel
  • Handle with large, adjusting push lever made of stainless steel, polished, valve not self-closing
  • high-performance spray head made of stainless steel for large-scale dispersion of water, polished, with plastic spray plate, low calcification, incl. rubber sleeves and sealed dust caps with folding mechanism
  • integrated flow regulation 7 litre / minute for a standard-compliant jet pattern at a specified working range of 1.5 to 5 bar flow pressure
  • integrated backflow preventer to protect the drinking water
  • stainless steel covered hose, length 1.5 meter, water inlet ½” female, DIN-DVGW tested and certificated
  • table mounting accessories M28x1,5x80mm made of stainless steel, incl. fastening-parts kit with nut M28x1,5mm and 2 screws M5 for mounting difficult to access, chrome-plated rosette, sealing to table surface with O-Ring
  • sign for eye shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 100 x 100 mm, viewing distance 10 metre
  • mounting height 770 mm (± 200 mm)
  • according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
  • according to ANSI Z358.1-2014 and EN 15154-2:2006
  • DIN-DVGW tested and certificated

Certification

DVGW    ISO9001_D_72.png
