Body safety shower above door installation in 2850 mm height - ClassicLine - BR 084 185 | B-Safety

Exceptional Protection and Convenience: Body safety shower above door installation in 2850 mm height - ClassicLine - BR 084 185 | B-Safety

The Body safety shower above door installation in 2850 mm height - ClassicLine - BR 084 185 | B-Safety offers a reliable solution for emergency safety in industrial environments. Built for rapid response, this advanced shower is designed to be installed above doors at a 2850 mm height, making it perfect for areas with limited space or where quick access is critical. This shower ensures the utmost safety for employees exposed to hazardous substances, providing immediate relief and peace of mind.

Features and Benefits of the Body safety shower above door installation in 2850 mm height - ClassicLine - BR 084 185 | B-Safety

  • Space-Saving Installation: Mounted above doorways at 2850 mm, the shower fits neatly into most industrial settings without blocking pathways or interrupting workflow.
  • Quick Activation: Engineered for fast response, a simple pull of the handle delivers a powerful stream, ensuring employees can act immediately in case of chemical exposure.
  • Durability: Constructed from high-quality, corrosion-resistant materials, this model withstands harsh environments and frequent usage, ensuring long-term reliability.
  • Wide Coverage: The showerhead is specially designed to provide full-body coverage, maximizing the effectiveness of decontamination in emergencies.
  • Complies with Safety Standards: Fully meets stringent safety requirements, ensuring compliance and peace of mind for management and staff.
  • Easy Maintenance: The straightforward design allows for hassle-free inspection and cleaning, making it easy to keep the system in top condition.

This body safety shower is an essential addition to any laboratory, factory, or industrial facility where safety is a top priority. Its above-door configuration makes it ideal for rooms where every centimeter counts, without sacrificing accessibility or efficiency. Install the Body safety shower above door installation in 2850 mm height - ClassicLine - BR 084 185 | B-Safety and empower your team with a practical, robust first line of defense against workplace accidents. Safeguard well-being, maintain compliance, and ensure a safer work environment with this innovative safety solution.

Datasheet and documents

Description

Technical Specifications

  • Material: stainless steel, plastic
  • Color: green, black
  • Projection: 525 mm
  • Installation height: 2850 mm (± 100 mm)
  • Operating pressure: 1.5 to 3 bar
  • Flow rate: 50 l/min (75/110 l/min)
  • Water inlet: ¾“ female

Norms / Approvals

  • EN 15154-2:2006
  • EN 15154-5:2019
  • ANSI Z358.1-2014
  • DIN-DVGW, DVGW, NW-0416CL0425
  • GOST-R, Certificate-No. 0615463 0615463

Product description

The body safety showers are equipped with the B-SAFETY high-performance shower head, which not only meets the specifications of ANSI Z358.1 and EN 15154, but is also self-draining, largely free of calcification and maintenance, and very robust and corrosion-resistant. The limited, uniform and above all soft water jet is optimized for rinsing off chemicals on the skin.

The integrated automatic flow regulator ensures a standard-compliant spray pattern regardless of the water pressure on site. With the enclosed safety sign according to EN ISO 7010 and ASR A1.3, the B-SAFETY emergency shower is marked and visibility is improved. The viewing distance is 15 meters.

DVGW
ISO9001_D_72

Technical Description

  • ball valve made of dezincification-resistant brass with pull rod actuation on wall flange, can be mounted either on the right or left side of the door, DIN-DVGW tested and certificated, water inlet ¾” female
  • pull rod with ring handle of stainless steel, chemical resistant green powder coated, length 1200 mm
  • holder for pull rod made of steel, chemical resistant green powder coated
  • connection pipe ¾“ of stainless steel, chemical resistant green powder coated, length 500 mm
  • wall flange with 4 mounting holes of stainless steel, chemical resistant green powder coated
  • wall shower arm ¾“ of stainless steel, chemical resistant green powder coated, projection 525 mm
  • integrated automatic flow regulation 50 l/min. for a spray pattern acc. to the norms at a specified operating range of 1.5 to 3 bar dynamic water pressure
  • coupling sleeve ¾“ of stainless steel, chemical resistant green powder coated
  • connection pipe ¾“ of stainless steel, chemical resistant green powder coated, length 500 mm
  • high-performance shower head of chemical resistant plastics, black, with improved spray pattern, corrosion resistant, largely scale and maintenance-free, very robust, self-draining
  • sign for body safety shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 150 x 150 mm, viewing distance 15 metre
  • mounting height 2850 mm (± 100 mm)
  • according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
  • according to ANSI Z358.1-2014, EN 15154-1:2006 and EN 15154-5:2019
  • DIN-DVGW tested and certificated
