ATEX Valves - Pneumatically actuated valves | Hafner | Philippopoulos s.a.

ATEX Valves - Pneumatically actuated valves | Hafner

Name: ATEX Valves - Pneumatically actuated valves | Hafner
Brand: Hafner
SKU: ATEX Valves - Pneumatically actuated valves | Hafner

Reliable Power and Safety: ATEX Valves - Pneumatically actuated valves | Hafner

Discover the robust solution for demanding industries with the ATEX Valves - Pneumatically actuated valves | Hafner. Built for environments where safety and reliability are essential, these valves combine advanced engineering with outstanding practicality. Perfect for use in potentially explosive atmospheres, these valves ensure your processes run smoothly while keeping safety at the forefront.

Features & Benefits of ATEX Valves - Pneumatically actuated valves | Hafner

Certified Safety: Designed to meet strict ATEX standards, these valves are ideal for hazardous locations, ensuring maximum protection for your workplace and staff.
Effortless Control: Pneumatic actuation means easy operation and fast response times, letting you precisely manage flow with minimal effort.
Built to Last: High-quality materials guarantee durability and minimal maintenance, providing long-term value under constant industrial use.
Reliable Performance: Even in tough conditions, these valves maintain excellent sealing and consistent operation, reducing downtime and unexpected repairs.
Versatile Applications: Suitable for a wide range of industries, from chemical and pharmaceutical plants to food processing and energy production.
Compact Design: Their space-saving shape allows easy installation in tight spots, making them a perfect fit for modern industrial setups.

With ATEX Valves - Pneumatically actuated valves | Hafner, you get the peace of mind that comes from using expertly crafted technology. Each valve is designed to make everyday operations safer and more efficient in dangerous environments. Their simple installation and robust construction mean you can trust your system will keep running at its best, no matter the pressure. Hafner’s smart technology helps your team work with confidence by reducing risks and simplifying control.

Choose ATEX Valves - Pneumatically actuated valves | Hafner for proven safety, uncompromising performance, and reliability where it counts most.

Datasheet and documents

Description

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 310 502 Ex	G 1/8"	650 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC

Explosion proof pilot actuated valve | monostable | NC | air spring return | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 310 501 Ex	G 1/8"	650 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC
P 310 701 Ex	G 1/4"	1250 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC
P 310 801 Ex	G 1/4"	1450 l/min	1,5...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC
P 310 101 Ex	G 3/8"	2250 l/min	1...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC
P 310 121 Ex	G 1/2"	3000 l/min	1...10 bar	Same as operating pressure	G 1/8"	single pilot \| NC

Explosion proof pilot actuated valve | bistable | all ports on one side | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 320 502 Ex	G 1/8"	650 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot

Explosion proof pilot actuated valve | bistable | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 320 501 Ex	G 1/8"	650 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 320 701 Ex	G 1/4"	1250 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 320 801 Ex	G 1/4"	1450 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 320 101 Ex	G 3/8"	2250 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 320 121 Ex	G 1/2"	3000 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot

Explosion proof pilot actuated valve | monostable | air spring return | all ports on one side | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 510 502 Ex	G 1/8"	650 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot

Explosion proof pilot actuated valve | monostable | air spring return | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 510 501 Ex	G 1/8"	650 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot
P 510 701 Ex	G 1/4"	1250 l/min	2...10 bar	Same as operating pressure	G 1/8"	single pilot
P 510 801 Ex	G 1/4"	1450 l/min	1,5...10 bar	Same as operating pressure	G 1/8"	single pilot
P 510 101 Ex	G 3/8"	2250 l/min	1,5...10 bar	Same as operating pressure	G 1/8"	single pilot
P 510 121 Ex	G 1/2"	3000 l/min	1...10 bar	Same as operating pressure	G 1/8"	single pilot

Explosion proof pilot actuated valve | bistable | all ports on one side | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 520 502 Ex	G 1/8"	650 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot

Explosion proof pilot actuated valve | bistable | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 520 501 Ex	G 1/8"	650 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 520 701 Ex	G 1/4"	1250 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 520 801 Ex	G 1/4"	1450 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 520 101 Ex	G 3/8"	2250 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot
P 520 121 Ex	G 1/2"	3000 l/min	1...10 bar	2,5...10 bar	G 1/8"	double pilot

Explosion proof pilot actuated valve | spring return to middle position | centre closed | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 531 501 Ex	G 1/8"	650 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre closed
P 531 701 Ex	G 1/4"	1250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre closed
P 531 801 Ex	G 1/4"	1450 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre closed
P 531 101 Ex	G 3/8"	2250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre closed
P 531 121 Ex	G 1/2"	3000 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre closed

Explosion proof pilot actuated valve | spring return to middle position | centre exhausted | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 532 501 Ex	G 1/8"	650 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre exhausted
P 532 701 Ex	G 1/4"	1250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre exhausted
P 532 801 Ex	G 1/4"	1450 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre exhausted
P 532 101 Ex	G 3/8"	2250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre exhausted
P 532 121 Ex	G 1/2"	3000 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre exhausted

Explosion proof pilot actuated valve | spring return to middle position | centre pressurised | ATEX

Type number	Port size	Air flow	Operating pressure	Actuating pressure	Size of actuation port	Function
P 533 501 Ex	G 1/8"	650 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre pressurized
P 533 701 Ex	G 1/4"	1250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre pressurized
P 533 801 Ex	G 1/4"	1450 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre pressurized
P 533 101 Ex	G 3/8"	2250 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre pressurized
P 533 121 Ex	G 1/2"	3000 l/min	1...10 bar	3...10 bar	G 1/8"	5/3-way \| centre pressurized
