Frostprotected heated body safety shower - PremiumLine - BR 810 095 | B-Safety

Ultimate Safety and Comfort: Frostprotected Heated Body Safety Shower - PremiumLine - BR 810 095 | B-Safety

Ensure maximum safety and peace of mind in your workplace with the Frostprotected Heated Body Safety Shower - PremiumLine - BR 810 095 | B-Safety. Crafted for outstanding performance in demanding industrial environments, this innovative safety shower guarantees reliable protection even in the coldest conditions.

Features & Benefits of Frostprotected Heated Body Safety Shower - PremiumLine - BR 810 095 | B-Safety

  • Frost Protection: Designed with advanced frost-protection technology, this safety shower remains fully operational even in freezing temperatures. Your team will always have quick access to emergency decontamination, regardless of the weather.
  • Consistent Water Temperature: The built-in heating system keeps water at a safe and comfortable temperature, preventing shock and promoting effective rinsing in emergencies.
  • Premium Durability: Manufactured with high-quality, corrosion-resistant materials, it withstands harsh industrial settings and heavy usage, year after year.
  • Easy Operation: Intuitive design ensures immediate activation with a simple pull lever, delivering a fast and steady flow of water when every second counts.
  • Reliable All-Year Performance: Whether it’s the depths of winter or high humidity, this safety shower keeps on working, ensuring your facility is always prepared for emergencies.
  • High Visibility: The clearly marked, bright design makes the shower easy to locate quickly, shortening response time in critical situations.
  • Minimal Maintenance: Engineered for easy inspection and upkeep, reducing downtime and keeping your safety systems in top shape.

The Frostprotected Heated Body Safety Shower - PremiumLine - BR 810 095 | B-Safety is ideal for industries where exposure to hazardous substances or extreme weather is a risk. Its robust structure and leading-edge features give you reliable emergency protection, no matter the season. Equip your facility with this advanced safety solution and provide workers with the confidence they need to focus on their tasks, knowing their welfare is secure.

Datasheet and documents

Description

Technical Specifications

  • Material: stainless steel
  • Surface: polished
  • Total height: 2300 mm
  • Projection: 600 mm
  • Minimum flow pressure: 2.0 bar
  • Operating pressure: 2 to 8 bar
  • Flow rate: 50 l/min (110 l/min)
  • Water inlet: 1 ¼” male
  • Electrical supply: 230 V – 50 Hz

Norms / Approvals

  • EN 15154-2:2006
  • EN 15154-5:2019
  • ANSI Z358.1-2014
  • DIN-DVGW, DVGW, NW-0416CL0425
  • GOST-R, Certificate-No. 0615463 0615463
  • GOST-TR-EX, Certificate-No. 0338358 0338358

Product description

The B-SAFETY body safety showers of the PremiumLine series are made of stainless steel and are just as suitable for use in laboratories and research as for rough use in industry. The polished stainless steel surface is not only resistant to many chemicals, but also offers a modern design for laboratories and clean rooms.

The body safety showers are equipped with the B-SAFETY high-performance shower head, which not only meets the specifications of ANSI Z358.1 and EN 15154, but is also self-draining, largely free of calcification- and maintenance, and very robust and corrosion-resistant. The limited, uniform and above all soft water jet is optimized for rinsing off chemicals on the skin.

ISO9001_D_72

Technical Description

  • base plate with 4 mounting holes of stainless steel , dimensions 200 x 200 mm
  • stand pipe 1 ¼” of stainless steel two-part, with bottom water inlet 1 ¼” female, total height 2300 mm
  • connection pipe 1 ¼” of stainless steel, length 75 mm
  • ball valve 1 ¼” of stainless steel, with pull rod actuation, DIN-DVGW tested and certificated
  • pull rod with ring handle of stainless steel, length 700 mm
  • wall shower arm 1 ¼” of stainless steel, polished, projection 600 mm
  • high-performance shower head of chemical resistant plastics, black, with improved spray pattern, corrosion resistant, largely calcification- and maintenance-free, very robust, self-draining
  • insulation made of mineral wool shape package, non-flammable, according to DIN 4102
  • heating by self-regulating trace tape, output 10 W/m, electrical supply 230 V – 50 Hz
  • outdoor thermostat and power-saving-circuit (shutdown of trace tape at 11°C, switch on at 4°C)
  • outer casing of the shower made of screwed stainless steel housing, easy to dismantle for maintenance work, including green/white indicator strips for better visibility of the shower
  • sign for body safety shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 150 x 150 mm, viewing distance 15 meter
  • suitable for use in EX-Zones 1 & 2, all electrical parts explosion-proof, with risk assessment in accordance with industrial safety regulations concerning the non-electrical and electrical explosion protection
  • according to BGI/GUV-I 850-0, DIN 1988 and EN 1717
  • according to ANSI Z358.1-2014, EN 15154-1:2006 and EN 15154-5:2019
  • DIN-DVGW tested and certificated
