The Sight Glass Indicators - Cast - GC | BLU ZAC are essential devices for monitoring fluid flow within pipes. These indicators feature a robust single cast flanged body with dual glass panes secured by flanges, allowing for clear observation of fluid movement. They can include either floating or static flow indicators for immediate and safe flow assessment. Custom versions are available to meet specific pressure and temperature requirements, making them suitable for diverse industrial applications. Available in sizes ranging from 2” to 24”, these indicators offer connection options such as Buttweld (BW) conforming to ANSI B16.25 and Flanged (FLG) conforming to ANSI B16.5 standards.

Datasheet and documents

Description

CASTING – FLOW INDICATOR

Sight glass indicators are pieces of equipment used to observe the flow of a fluid in a pipe.

Comprising a single cast flanged body, with two pieces of glass held in place by two flanges, the sight glass indicator may contain a floating or static flow indicator, which allows for instant, safe monitoring of flow inside the pipe.

On request, special versions for pressures and temperatures specified by the customer can be produced for use in a wide variety of industrial applications.

SIZES
from 2” to 24”
CONNECTIONS
Buttweld BW ANSI B16.25
Flanged FLG ANSI B16.5

Certifications

Optimum result at the lowest cost working alongside client, we design, construct and manage high-performance components.

Our mission, based on a tried-and-tested approach, is to create the perfect balance between people, machines and passion. The right people to understand, develop and realize a project, the machines to design and build it and the passion to get satisfaction from what we do and to keep improving, day after day. Everything produced by Blu Zac is based on a ISO 9001-certified quality control system, and every filter is designed, constructed and tested in accordance with ASME, UNI, API and EN regulations.
