The Needle Valve Clamp - GRADUATE HANDWHEEL - 658230 by 4G Ghidini is a precision-engineered valve designed for reliable flow control. It features a PIN valve mechanism driven by a GRADUATE handwheel for precise adjustments. The valve connects via a CLAMP system compliant with DIN 32676 standards (TAB.4 REIHE C and TAB.2 REIHE A) and is constructed from durable Aisi 316L stainless steel. Available in sizes ranging from 1/2” to 1”, it operates efficiently within a temperature range of -20°C to +160°C. The valve boasts a polished outer finish for enhanced durability and aesthetics. Optional features include an antistatic device compliant with ATEX standards (II 2G Ex h IIC T4 Gb and II 2D Ex h IIIC T135°C Db) and M.O.C.A. certification according to CE 1935/2004.
Standard (Options)
  • DIN
Connection (Options)
  • Clamp
Material (Options)
  • 1.4404
Pressure Rating (Options)
  • PN 100
  • PN 160

Datasheet and documents

Description

PIN valve

Drive: GRADUATE Handwheel

Connection: CLAMP normative DIN 32676 TAB.4 REIHE C e TAB.2 REIHE A

Material: Aisi 316L

Measure: from 1/2” to 1”

Operating temperature: -20°C+160°C

Outer finish: Polished

On request:

Antistatic device ATEX:

II 2G Ex h IIC T4 Gb

II 2D Ex h IIIC T135°C Db

M.O.C.A. CE 1935/2004
