The Gate Valve PN 16 - 2220 by Genebre is a robust and reliable valve designed for controlling the flow of liquids in various industrial applications. It features a flanged connection and is rated for a pressure of PN 16, making it suitable for medium-pressure systems. The valve is constructed from durable materials to ensure longevity and resistance to wear and corrosion. Its design allows for minimal pressure drop and provides a tight seal when closed, ensuring efficient operation. Ideal for use in water supply systems, HVAC, and other industrial processes, the Genebre Gate Valve PN 16 - 2220 is a versatile and essential component for fluid control.
Standard (Options)
  • DIN
Connection (Options)
  • BSP
Material (Options)
  • 1.4408
Pressure Rating (Options)
  • PN 16
Seat (Options)
  • PTFE

Datasheet and documents

Description

Constr. stainless steel CF8M (316) investment casting.

Gasket: PTFE: gas threaded ends ISO 7-1 (EN 10226-1).

Max. pressure: 16 BAR at 120ºC - 10 BAR at 180ºC.

Minimum temp.: -30ºC.

Reference: 2220

ReferenceSizeMinimum purchase unitWeight (Kg)Box / carton
2220 04GATE VALVE PN 16 1/2"10.4146/48
2220 05GATE VALVE PN 16 3/4"10.5534/32
2220 06GATE VALVE PN 16 1"10.692/18
2220 07GATE VALVE PN 16 1 1/4"11.0882/16
2220 08GATE VALVE PN 16 1 1/2"11.5061/8
2220 09GATE VALVE PN 16 2"12.141/6

Certificates

GENEBRE, S.A. has implemented a quality management system to control the designing and manufacturing of fluid control valves, as well as the distribution of home and public taps.

This system complies with the requirements of the current international UNE-EN-ISO 9001:2015, certified by the prestigious German certification organization TÜV Rheinland.

In 2000, GENEBRE began to comply with the European Business Excellence Model, more commonly known as the EFQM. As a result, in 2003, the Catalan Regional Government awarded us with the Quality Award. This new system enables us to ensure the quality of GENEBRE's products and also to offer added value to our clients.

In 2012, we obtained the certification for the Environmental Management System. This system is certified according to the UNE-EN-ISO 14001:2015, also by TÜV Rheinland. GENEBRE QUALITY AND ENVIRONMENTAL POLICY
