The 3 Way (T) Ball Valve with Heating Jacket by 4G Ghidini, model 300130C, is a versatile valve designed for efficient fluid control. It features a three-way ball valve with a "T" port and four seals, ensuring reliable operation. The valve is equipped with a heating jacket to maintain optimal temperature conditions. It is operated via an inox lever and offers various connection options compliant with DIN 32676 standards for different tube norms (BS/OD, DIN 11850, ISO 1127). The valve supports both full and reduced flow and is constructed from durable Aisi 304L and Aisi 316L materials. Available in sizes ranging from 1/2” to 4” (DN10 to DN100), it is suitable for operating temperatures between -20°C and +170°C. The outer finish is polished for a sleek appearance. Optional features include an antistatic device compliant with ATEX standards and seals made from various PTFE composites for enhanced temperature resistance.
Standard (Options)
  • DIN
Connection (Options)
  • Clamp
Material (Options)
  • 1.4307
  • 1.4404
Pressure Rating (Options)
  • PN 16
  • PN 40
Seat (Options)
  • PTFE Virgin (Modified)

Datasheet and documents

Description

THREE-way ball valve 4 seals with “T” port with HEATING JACKET

Drive: Inox lever

Connection:

  • CLAMP normative DIN 32676 TAB.4 REIHE C For TUBE according to normative BS/OD (ASTM A270)
  • CLAMP normative DIN 32676 TAB.2 REIHE A For TUBE according to normative DIN 11850
  • CLAMP normative DIN 32676 TAB.3 REIHE B For TUBE according to normative ISO 1127

Flow: Full and reduced

Material: Aisi 304L (1.4307) – Aisi 316L (1.4404)

Measure:

  • from 1/2” to 4”
  • from DN10 to DN100

Seals: Modified Virgin P.T.F.E.

Operating temperature: -20°C+170°C

Outer finish: Polished

On request:

Antistatic device ATEX:

II 2G Ex h IIC T4 Gb

II 2D Ex h IIIC T135°C Db

M.O.C.A. CE 1935/2004

• Seals made of:

PTFE with glass -20°C+170°C

PTFE with carbographite -20°C+180°C

PTFE with inox -20°C+200°C

UHMW High-molecular weight polyethylene -20°C+80°C
