Const.: stainless steel CF8M (316) investment casting. Seats and seats: PTFE +15% GF o’ring stem: viton PN 63. Temp. -25ºC +180ºC. Manually operated by handle. Direct assembling ISO 5211 with locking system.
1000 WOG -13ºF + 356ºF
Indicate necessary angle 30º, 60º or 90º; see extension XX.
Reference: 2026V
| Reference | Size | Minimum purchase unit | Weight (Kg) | Box / carton |
| 2026V 30 04 | V30 CONTROL VALVE 2026 3 PIECES 1/2" | 1 | 0.68 | 1/1 |
| 2026V 30 05 | V30 CONTROL VALVE 2026 3 PIECES 3/4" | 1 | 0.792 | 1/1 |
| 2026V 30 06 | V30 CONTROL VALVE 2026 3 PIECES 1" | 1 | 1.02 | 1/1 |
| 2026V 30 07 | V30 CONTROL VALVE 2026 3 PIECES 1 1/4" | 1 | 1.888 | 1/1 |
| 2026V 30 08 | V30 CONTROL VALVE 2026 3 PIECES 1 1/2" | 1 | 2.477 | 1/1 |
| 2026V 30 09 | V30 CONTROL VALVE 2026 3 PIECES 2" | 1 | 3.562 | 1/1 |
| 2026V 30 10 | V30 CONTROL VALVE 2026 3 PIECES 2 1/2" | 1 | 8.814 | 1/1 |
| 2026V 30 11 | V30 CONTROL VALVE 2026 3 PIECES 3" | 1 | 12.637 | 1/1 |
| 2026V 30 12 | V. 2026V | 1 | 19.896 | 1/1 |
| 2026V 60 04 | V60 CONTROL VALVE 2026 3 PIECES 1/2" | 1 | 0.423 | 1/1 |
| 2026V 60 05 | V60 CONTROL VALVE 2026 3 PIECES 3/4" | 1 | 0.792 | 1/1 |
| 2026V 60 06 | V60 CONTROL VALVE 2026 3 PIECES 1" | 1 | 1.02 | 1/1 |
| 2026V 60 07 | V60 CONTROL VALVE 2026 3 PIECES 1 1/4" | 1 | 1.881 | 1/1 |
| 2026V 60 08 | V60 CONTROL VALVE 2026 3 PIECES 1 1/2" | 1 | 2.462 | 1/1 |
| 2026V 60 09 | V60 CONTROL VALVE 2026 3 PIECES 2" | 1 | 3.532 | 1/1 |
| 2026V 60 10 | V60 CONTROL VALVE 2026 3 PIECES 2 1/2" | 1 | 8.774 | 1/1 |
| 2026V 60 11 | V60 CONTROL VALVE 2026 3 PIECES 3" | 1 | 12.537 | 1/1 |
| 2026V 60 12 | V60 CONTROL VALVE 2026 3 PIECES 4" | 1 | 19.746 | 1/1 |
| 2026V 90 04 | V90 CONTROL VALVE 2026 3 PIECES 1/2" | 1 | 0.422 | 1/1 |
| 2026V 90 06 | V90 CONTROL VALVE 2026 3 PIECES 1" | 1 | 1.015 | 1/1 |
| 2026V 90 08 | V90 CONTROL VALVE 2026 3 PIECES 1 1/2" | 1 | 2.452 | 1/1 |
| 2026V 90 09 | V90 CONTROL VALVE 2026 3 PIECES 2" | 1 | 3.517 | 1/1 |
| 2026V 90 10 | V90 CONTROL VALVE 2026 3 PIECES 2 1/2" | 1 | 8.734 | 1/1 |
| 2026V 90 11 | V90 CONTROL VALVE 2026 3 PIECES 3" | 1 | 12.477 | 1/1 |
| 2026V 90 12 | V90 CONTROL VALVE 2026 3 PIECES 4" | 1 | 19.606 | 1/1 |
