Pressure reducing valves - XLC 310/410 (RP 115) | Mankenberg

Pressure reducing valves - XLC 310/410 (RP 115) | Mankenberg: Ultimate Water Pressure Control

Experience seamless water management with the Pressure reducing valves - XLC 310/410 (RP 115) | Mankenberg. Designed for reliability and efficiency, these valves ensure steady water pressure wherever you need it. Ideal for domestic, commercial, or industrial use, the XLC 310/410 (RP 115) provides superior performance and lasting value.

Features & Benefits of the Pressure reducing valves - XLC 310/410 (RP 115) | Mankenberg

  • Consistent Pressure: Enjoy stable water pressure every time. The valve automatically adjusts to changes, protecting your system from surges and drops.
  • Durable Design: Made with high-quality materials, this valve stands up to harsh conditions and heavy use, ensuring reliable operation over the long term.
  • Easy Installation: The compact form and straightforward setup make it easy for anyone to get started, with minimal maintenance required.
  • Energy Efficient: By keeping water pressure optimal, these valves help conserve energy and reduce water waste, saving on utility costs.
  • Safe & Clean: Specially designed for water use, the valve protects against contamination and maintains water purity.
  • Wide Range: Suitable for small households or large industrial systems, the XLC 310/410 (RP 115) adapts effortlessly to your needs.

The advanced engineering in the XLC 310/410 (RP 115) keeps your water flow smooth and even. It acts instantly when pressure changes, preventing any risk of burst pipes or leaks. With this valve, there’s no need to worry about sudden changes affecting your showers, appliances, or pipes.

Installation is quick and straightforward, allowing you to upgrade your water system without extra hassle. Built from robust, corrosion-resistant materials, the valve can handle demanding environments and still keep working flawlessly.

With the Pressure reducing valves - XLC 310/410 (RP 115) | Mankenberg, you get a smart solution that’s easy to use and built to last. It’s the perfect fit for anyone wanting efficient, safe, and stress-free water pressure control.

Standard (Options)
  • DIN
Connection (Options)
  • Flanged
Material (Options)
  • Cast Iron
Pressure Rating (Options)
  • PN 10
  • PN 16
  • PN 25

Datasheet and documents

Description

Product features

Standard

  • Body made of spheroidal cast iron GJS 450-10
  • Epoxy coating as per DVGW W270 and KTW recommendation of the German Ministry for Health, thickness min. 250 μm
  • Internal parts, pilot valve and piping made of stainless steel 1.4301
  • Adjustable closing, opening and response speed

Options

  • Set pressures < 0.7 bar and also up to 25 bar
  • Pressure stages PN 10, PN 25
  • Body with reduced flow rate
  • Throttle cone, anti cavitation cone
  • Special designs such as differential pressure control valve, flow control valve, float valve, others on request

Technical data

DN
40 - 600
PN
10, 16, 25
p1
up to 25 bar
p2
0.7 - 7 / 1,5 - 15 / 8 - 24 bar
Kvs
20 - 3235 m3/h
T
70 °C

Advantages

xlc420-rp116-schnitt
1

Opening and closing velocities can be set via throttles

Optimal control behaviour

2

Control block with integrated fine filter

Easy to clean

3

Position Indicator

Optical function control

4

„Freezing“ of sense line and control hammer by closing the ball valves

Cleaning / maintenance of control block and pilot valve can be performed during ongoing operation

5

Body made of GIS 450-10 with epoxy coating (min. 250 μm)

Strong corrosion protection acc. to KTW recommendation and DVGW worksheet W270

6

Precise control through pilot valve

Very high control accuracy without external energy

7

Compact design

Minimum space required, easy transport

Options

a

Various seat inserts

Optimal adaptation to various operating conditions

Inlet Pressure

Outlet Pressure

Control Pressure
